| Technical Details of UV Germicida lamps | |||||||||
| Model No. | Dia | length | arc length | Power | Current | Volt | 1M UV intensity | UVCW | |
| mm | mm | mm | W | mA | V |
μWcm2 (254nm) |
UVCW | ||
| GPH212T5L | 15 | 212 | 132 | 10 | 425 | 30 | 26 | 2.7 | |
| GPH212T5VH | 15 | 212 | 132 | 10 | 425 | 30 | 26 | 2.7 | |
| GPH265T5L | 15 | 265 | 185 | 12 | 425 | 35 | 34 | 3.4 | |
| GPH265T5VH | 15 | 265 | 185 | 12 | 425 | 35 | 34 | 3.4 | |
| GPH287T5L | 15 | 287 | 207 | 14 | 425 | 41 | 40 | 4 | |
| GPH287T5VH | 15 | 287 | 207 | 14 | 425 | 41 | 40 | 4 | |
| GPH357T5L | 15 | 357 | 277 | 17 | 425 | 51 | 57 | 5.7 | |
| GPH357T5VH | 15 | 357 | 277 | 17 | 425 | 51 | 57 | 5.7 | |
| GPH436T5L | 15 | 436 | 356 | 21 | 425 | 62 | 72 | 7.3 | |
| GPH436T5VH | 15 | 436 | 356 | 21 | 425 | 62 | 72 | 7.3 | |
| GPH793T5L | 15 | 793 | 713 | 38 | 425 | 112 | 125 | 13.5 | |
